  • Unscreened 6 Core Security Alarm Cable
Unscreened 6 Core Security Alarm Cable

Unscreened 6 Core Security Alarm Cable

  • Conductor:Electrolytic Copper Conductor
  • MOQ:10KM
  • Use:indoor signal and data transfer
  • Packing: roll, wooden spool, carton, pallet
  • Product description: unscreened 6 core security alarm cable
  • INQUIRY    EMAIL
Product Description:

unscreened 6 core security alarm cable


Conductor Material : Tinned Copper, 7/0.2mm

Conductor Insulation : Low Smoke Halogen Free (LSHF)

Outer Sheath Material : Low Smoke Halogen Free (LSHF)

Outer Sheath Colour : White

Core Identification

1 Red    2 Blue

3 Yellow  4 Black

5 White   6 Green

7 Orange  8 Brown

9 Grey   10 Pink

11 Violet 12 Turquoise


Electrical Characteristics

Maximum Conductor Resistance : < 100 /km

Voltage Rating : 50V

Current Rating : 1.0 amp

Physical Characteristics

Min. Bend Radius : 7.5 x OD

Temperature Rating : 0°C to 70°C

Weight : See table


Standards

Manufactured to : BS 4737-3:30, Type 1

Flame Retardant : EN 60332-1-2

RoHS2 Compliant : Yes

CE Compliant : LVD (2014/35/EU), CPR (305/2011)

CPR Classification : ECA (EN50575:2014+A1:2016)

No. Of Cores   O/D(mm)     Weight(kg/km)

4               3.4          18

6               4.0          25

8               4.3          30

12              5.5          37
